Powerful High Head Pump For Forest Fire Fighting Energy Saving Environmental Protection Ultra-Long Working Time

Brand Name : TOPSKY

Model Number : TSP7.0

Place of Origin : China

MOQ : 1 set

Price : USD12000-13000

Payment Terms : T/T

Supply Ability : 50 Sets/Month

Delivery Time : 15 working days

Packaging Details : Export package

Engine Type : V-twin, four-stroke, air-cooled, overhead valves

Engine Power : ≥25KW (35HP)

Engine Starting System : Electric start

Total Weight : ≤180kg

Max Flow Rate : ≥185L/min

Max Pressure : 5MPa

Contact Now

Powerful High Head Pump For Forest Fire Fighting Energy Saving Environmental Protection Ultra-Long Working TimePowerful High Head Pump For Forest Fire Fighting Energy Saving Environmental Protection Ultra-Long Working TimePowerful High Head Pump For Forest Fire Fighting Energy Saving Environmental Protection Ultra-Long Working TimePowerful High Head Pump For Forest Fire Fighting Energy Saving Environmental Protection Ultra-Long Working Time

1.Product Overview
The high-head pump is a large-flow pump developed by our company to adapt to the special working environment of forest fire fighting. It realizes advantages of energy saving and environmental protection of the engine, stable output, strong power, and ultra-long working time. The pump has a larger flow, higher head and longer conveying distance. The pump unit adopts an engine and diaphragm pump, with a lightweight, compact structure, small footprint, and good stability. It hand-held and cart-mounted designs, making it easy to carry and operate. Users only need simple training to operate it proficiently. It can be used in foresting to convey water sources to the fire scene for firefighting from a distance. The high-pressure forest fire pump for long-distance conveyance is also suitable for firefight in small and medium-sized towns, rural areas, and mines where fire trucks cannot arrive in time or cannot reach the center of the fire.
2.Scope of Application

1. Grassland fire fighting

2. Forest fire prevention and control

3. Mountain fire fighting

4. Urban fire fighting

3.Product Features
  • ★Large flow;
  • ★Equipped with gas detection function
  • ★Equipped with panoramic monitoring function;
  • ★Equipped with night lighting function.
  • ★Equipped with real-time positioning function

4.Technical parameters
  • Engine Type: V-twin, four-stroke, air-cooled, overhead valves
  • Max Engine Power: ≥25KW (35HP)
  • Engine Starting System: Electric start
  • Pump Structure: Four-cylinder diaphragm pump, gearbox is a planetary
  • Total Weight: ≤180kg
  • Overall Dimensions: ≤900×650×670 mm
  • Max Flow Rate: ≥185L/min
  • Max Pressure: 5MPa
  • Max Head: 500m ( height)
  • Max Range: ≥25m
  • Max Suction: ≥7m
  • Inlet Port Size:DN40
  • Outlet Port Size: DN40
  • Priming Time: ≤5s
  • Priming Method: suction, no water filling required
  • Pan-tilt: 2.7~12 mm, 4x optical/uses high-efficiency infrared array, low power consumption, illumination distance up to 50m; rotation range: 350° horizontal rotation,0°~90° vertical rotation; network transmission: 4G
  • Lighting system: uses 36 LEDs, with a power of 108W
  • Equipped with a remote intelligent gas detection alarm system, with the following technical parameters:
  • Detection types: Carbonoxide [This parameter is consistent with the national inspection report]
  • Positioning mode: supports GPS positioning, with a positioning accuracy error ≤3 meters [ parameter is consistent with the national inspection report]
  • Network mode: supports 4G/5G ultra-long-distance data transmission [This parameter is consistent the national inspection report]
  • Cloud platform management: can remotely monitor the gas status of the equipment in real-time, and manage the entire life cycle [ parameter is consistent with the national inspection report]
  • Visual management: supports visual display, GIS map positioning, and graphic display functions [This parameter is consistent the national inspection report]
  • Multi-platform management: supports interaction between PC and APP, with real-time automatic data synchronization [This parameter is consistent with the inspection report]
  • The toxic and harmful gas detection alarm system for special disaster rescue has passed the national authoritative inspection institution, and a copy of the certificate provided.
  • Has a measuring instrument type approval certificate (CPA) [A copy of the measuring instrument type approval certificate, with the manufacturer's seal is provided as proof]
  • Provides software copyright certificates for the [Emergency Firefighting Equipment Cloud Management Platform System] and [Emergency Resource Information Management Platform
